CITROEN
CITROEN C4 MAX HYBRID
General Specification
People who viewed this also viewed
Model3AA-C41HN09
Dimension4375×1800×1530mm
Wheelbase2665mm
Tread front/rear1560/1560mm
Dimension(Interior)-×-×-mm
Weight1370kg
Body TypeHatch
Doors5
Riding Capacity5
Specifications
Engine/Fuel
| Engine Model | - |
|---|---|
| Maximum Power | 136ps(100kW)/5500rpm |
| Displacement | 1199cc |
| Compression Ratio | 11.5 |
| Fuel Supply Equipment | - |
| Fuel Type | - |
| Cylinders | - |
| Maximum Torque | 23.5kg・m(230N・m)/1750rpm |
| Bore×Stroke | 75.0mm×90.5mm |
| Charger | - |
| Fuel Tank Equipment | 50L |
Suspension
| Steering System | - |
|---|---|
| Suspension System(front) | - |
| Breaking System(front) | - |
| Tires Size(front) | 195/60 R18 |
| Minimum Turning Radius | 5.6m |
| Suspension System(rear) | - |
| Breaking System(rear) | - |
| Tires Size(rear) | 195/60 R18 |
Drivetrain
| Driving Wheel | FF |
|---|---|
| Transmission | 6AT |
| LSD | |
| Gear_ratio |
1st Gear17.391 2nd Gear10.570 3rd Gear6.657 4th Gear5.070 5th Gear3.749 6th Gear2.849 Reverse15.527 |
| Final Drive Gear Ratio | 1.000 |
